产品描述
产品描述
|
|
Parameter name
|
1.2KW
|
3.6KW
|
6KW
|
||
|
AC Input
|
Main topology
|
L+N+PE
|
|
|
||
|
|
Nominal Voltage
|
230V
|
|
|
||
|
|
Input Voltage Range
|
90~280V 170~264V
|
|
|
||
|
|
Frequency Range
|
40-70Hz(APP MODE/GEN MODE) Set Frequency(50Hz or 60Hz)±10Hz(UPS MODE )
|
|
|
||
|
|
Power Fa ctor
|
≥0.9
|
≥0.99
|
≥0.99
|
||
|
PVInput
|
Max Voltage
|
115V
|
500V
|
500V
|
||
|
|
Max input current
|
18A
|
18A
|
27A
|
||
|
|
Max Input Power
|
800W
|
5000W
|
9000W
|
||
|
|
MPPT
|
17-115Vdc
|
40-450Vdc
|
60-450Vdc
|
||
|
|
voltage
|
20V
|
60V
|
80V
|
||
|
Max charging current
|
/
|
100A
|
100A
|
120A
Default100A |
||
|
AC Output
|
Output Voltage
|
208/220/230/240VAC
|
|
|
||
|
|
Voltage Regulation
|
≤±5%
|
|
|
||
|
|
Power factor
|
1
|
|
|
||
|
|
Frequency Range
|
Line Mode: Synchronized range, Battery Mode:50/60Hz+0.1%
|
|
|
||
|
|
Output Power
rating |
1.2KVA
|
3.6KVA
|
6KVA
|
||
|
|
Over load Capacity
|
1min @102%
|
|
|
||
|
Battery
|
Nominal Voltage
|
12V
|
24V
|
48V
|
||
|
|
charging Current
|
2~50A
|
2~100A
|
2~120A
|
||
|
Battery
protection |
Battery over Voltage
|
16V
|
30.5V
|
61V
|
||
|
|
Battery under voltage
|
10.5V
|
10.5V*N
|
10.5V*N
|
||
|
|
Battery low voltage alarm
|
11V
|
10.8V*N
|
10.8V*N
|
||
|
|
Over current protection过
|
Fuse
|
|
|
||
|
Environment
|
Ambient temperature
|
-10℃~60℃
|
|
|
||
|
|
Humidity
|
20%~95%(Nocondensing)
|
|
|
||
|
|
Storage temperature
|
-15℃~60℃
|
|
|
||
|
Communication
|
RS232 Port
|
5PIN/Pitch2.0mm
|
|
|
||
|
|
Expansion port
|
2x13PIN/Pitch2.0mm+1x12PIN/Pitch2.0mm
|
|
|
||
|
|
Overall size
|
377*269*165mm
|
518*342*170mm
|
490*394*181mm
|
||
|
|
Machine weight
|
4.2KG
|
7.3KG
|
9.5KG
|
||
